Please Note:
These are not available for purchase online. This is purely for informational and pricing purposes. Please contact us directly via phone or email for details on MoTeC products for your project.
While you're here: Please check out our other MoTeC and other products HERE.
FEATURES
- Full HD: Genuine High Definition with 1080p @ 30 frames per second
- Automatic Start/Stop, eliminating the possibility of drivers forgetting to turn it on
- 12 V power direct from the vehicle - no batteries to recharge
- Live gauges automatically recorded on the video
- Recording time from 4hrs 51min to 72hrs 46mins depending on bitrate setting when used with a 32GB card.
- Records to a removable storage memory card up to a maximum size of 32GB
- Video can be played directly from the card
- Automatic CAN Synchronisation with data in i2
- Compact, lightweight recording unit
- Built in microphone
RECORDING FORMATS - ALL AVAILABLE WITH OR WITHOUT LIVE GAUGES
- 1920 x 1080 @ 30 fps (1080p)
- 1920 x 1080 @ 25fps
- 1280 x 720 @ 60 fps
- 1280 x 720 @ 50 fps
- 1280 x 720 @ 30 fps (720p)
- 1280 x 720 @ 25 fps
COMPATIBILITY
- Current MoTeC Data Loggers: CDL3, ADL3, ACL, C185, C187, C1812, C125, C127, C1212
- Previous MoTeC Dash Loggers: SDL, SDL3, ADL2, ADL
- MoTeC M1 Series ECUs (depending on Package)
- The HD- VCS can be used standalone but no data will be overlaid onto video footage
- Works with i2 Pro and i2 Standard
KIT CONTENTS
- V2 - Video Recorder
- 32 GB SD Card
- V2 Power / CAN Loom
- V2 Mounting Kit
GAUGE OVERLAY
V2 Video can have the following data overlaid, depending on the sensors installed.
- Throttle Position: displayed as a green bar graph scaled between 0% and 100%
- Ground Speed: displayed as numeric value from 0 to 999 kph
- RPM: displayed as a gauge from 0 to 10000 rpm
- G-Force: displayed as a G circle from 0 to 2 G with an indicator point
- Brake Switch or Pressure: displayed as a red bar graph
- Gear: displayed as numeric value
Lap Number, Last Lap Time, Running Lap Time are currently in development and will be available in a future release.
