We are very excited for the release of Link's latest Neo ECUs!
We'll be providing support and wiring harnesses for these as soon as possible. Please reach out with your interests and questions.
The G5 Voodoo Neo comes in two versions, with options to suit a wide range of engines.
The G5 Voodoo Neo 4 can run:
- 4 cylinders with staged sequential injection, a single high pressure fuel pump and direct spark, or
- a 6 cylinder as sequential only with DI* or Port, and direct spark.
The G5 Voodoo Neo 6 can run :
- 6 cylinders with staged sequential injection, dual high pressure fuel pumps and direct spark, or
- an 8 cylinder as sequential only with DI* or Port, and direct spark.
* Direct Injection (DI) requires an external OEM or aftermarket DI driver box, such as Link's DI Driver-4.
Highlights for both versions include:
- An all new communications module: 10x faster USB speeds (from minutes down to seconds to download log files), Ethernet, and enhanced WiFi and GPS.
- 1GB onboard of logging memory, double that of other Link ECUs.
- Highly customisable IO, using 2 types of multi purpose pins: Injection/Ignition/Aux pins and dual-purpose ADIO pins.
- Dual on-board E-throttle, with H-bridges that now natively support things like modern e-wastegates or e-blow off valves
- 1 onboard wideband
- Configurable Analogue Temp inputs, with two different pull up resistor values (1kΩ and 10 kΩ) , allowing more types of sensors to be used
- Analogue Temp pull-ups can be disabled now, allowing Analogue Temps to be used as regular Analogue Volt inputs.
- K-line support.
- CNC Case, Sealed enclosure
Huge time and flexibility gains for Installers:
- You can now power via the USB cable, just like the Razor PDM, making setting up the initial tune a breeze at your PC.
- More mounting options than ever before, with through holes, and threaded mount holes on the side and underneath.
- New WEIPU CAN connector supplies power for CAN devices, massively simplifying CAN wiring and accessory installation.
- Highly customisable IO, with multi-use pins to maximize utilisation.
- Similar pinouts to G4X, allowing upgrades with minimal repinning.
